运算放大器

运算放大器

运算放大器（运放）是模拟信号链的重要组件，通常是传感器与ADC之间接口的重要组成部分。常见的模拟运算放大器功能包括增益、缓冲、滤波和电平转换。ADI公司的产品系列拥有广泛的运算放大器选择，具有出色的质量、可靠性和性能，面向汽车、工业、消费电子和医疗健康市场提供优化的解决方案。可按参数搜索浏览运算放大器，并通过参考设计(Circuits from the Lab^®)、设计工具、选型指南、滤波器设计、计算器和运算放大器的LTSpice^®/SPICE模型，查找相关设计问题的系统级专家建议。

显示更多

查看产品

Precision Op Amps

Analog Devices’ broad range of precision operational amplifiers (op amps) provides industry-leading support to designers in need of traditional trimmed and zero-drift amplifier technology. Our precision op amp family helps preserve the accuracy of DC information in an incoming signal with low offset voltage (Vos < 1 mV) and low temperature drift characteristics (TCVos < 2 μV/°C).

Zero-Drift Op Amps

The latest zero-drift operational amplifiers (op amps) from Analog Devices combine both auto-zero and chopping techniques to continuously self-correct for DC errors over time and temperature. This enables the op amps to achieve <4 µV of input offset error and input drift error of <20 nV/°C. By design, zero-drift op amps have no 1/f voltage noise, nor do they suffer from long-term drift, making them ideal for low speed sensing. By reducing the drift and noise, these products decrease the need for constant system-level calibration. Additionally, very small LFCSP packages reduce board space, and on-chip electromagnetic interference filters speed development time by eliminating the need for collaboration circuitry. They accomplish all these features while controlling cost. ADI’s zero-drift op amp portfolio is an ideal choice for high performance projects and in products that are required to have a long lifecycle.

高速运算放大器

高速运算放大器用于仪器仪表、电信、实验室和医疗系统中的高性能数据采集系统。ADI公司提供高速运算放大器产品系列，速度范围为50 MHz至GHz，可大幅降低功耗，是当今全球畅销的高速放大器品牌。无论是在宽带宽、高摆率还是低失真方面，ADI都为下一代设计树立了性能标杆，并拥有丰富的产品系列。设计人员希望使用性能可靠、值得信赖的器件来设计高性能的产品，而ADI公司正是高速运算放大器的理想供应商。

轨到轨运算放大器

ADI公司的高速(>50 MHz)轨到轨运算放大器支持以较低的电源电压工作，摆幅更接近供电轨，并提供更宽的动态范围。ADI公司提供市场上最丰富的尖端产品系列，其运算放大器产品种类丰富，包括轨到轨输入/输出型以及仅轨到轨输出型。无论是宽带宽、高压摆率、低失真还是轨到轨，惟有ADI公司能够为下一代设计建立如此之多的性能标准。

ADHV4710

预发布

110V High Voltage, 1A High Current, Operational Amplifier

ADA4620-2

预发布

具有轨至轨输出的 36 V、精密、低噪声、16.5 MHz 结型场效应管运算放大器

ADA4620-1

预发布

具有轨至轨输出的 36 V、精密、低噪声、16.5 MHz 结型场效应管运算放大器

RH6016S

预发布

Aerospace, Dual 3.2MHz, 0.8V/μs Low Power, Over-The-Top Precision Op Amp Channel

ADA4510-2

推荐新设计使用

采用DigiTrim技术的精密、40 V、±70 nV/°C、轨到轨输入和输出运算放大器

ADUM3195

推荐新设计使用

具有可调增益和单端输出的隔离式放大器

ADUM4195

预发布

Isolated Amplifier with Adjustable Gain and Single-Ended Output

ADUM4195-1

推荐新设计使用

具有固定增益和单端输出的隔离式放大器

ADA4097-2

推荐新设计使用

50 V、130 kHz、每通道32.5 μA、稳定可靠的Over-The-Top精密运算放大器

ADA4077-4S

推荐新设计使用

4 MHz、7 nV/√Hz、低失调和漂移、高精度四通道放大器，适用于航空领域

Analog Filter Wizard Design Tool

Use the Analog Filter Wizard to design low-pass, high-pass, or band-pass filters with actual op amps in minutes. As you progress through the design process, you can observe the characteristics of your filter design from ideal specifications to real world circuit behavior. Quickly evaluate the tradeoffs in op amp specifications - including gain-bandwidth, noise, and supply current – to determine the best filter design for your requirements.

Learn More
