MAX96714R

RECOMMENDED FOR NEW DESIGNS

Single GMSL2/GMSL1 to CSI-2 Deserializer

Data Sheet (Rev. 2)

Part Models: 4
1ku List Price: Starting From $3.75

Viewing:

Part Details

Automotive Grade High-Speed Link
- -18dB at 3GHz (6Gbps) Max Insertion Loss
- -19.5dB at 1.5GHz (3Gbps) Max Insertion Loss
- Auto Adapt for Changes in Channel Conditions
- Operates -40°C to +105°C Ambient
Single GMSL Input Can Support up to 8MP Imagers
- 6/3Gbps in GMSL2 Forward Link-Rates
- 3.12Gbps in GMSL1 Forward Link-Rates
- 187.5Mbps/1Mbps (GMSL2/1) Reverse Link-Rates
High-Speed 1x4-lane MIPI Output Port, CSI-2 v1.3
- MIPI D-PHY v1.2 Rated at 2.5Gbps/Lane
- Polarity Flip and Data-Lane Reassignment
- Supports 16 Virtual Channels

Bidirectional Reverse Channel Supports
- Nine Configurable GPIOs
- 1 x I2C/UART Ports, up to 1MHz
- 2 x Pass-Through I²C/UART
Reduces BOM and Space Savings
- Tiny 5mm x 5mm TQFN Standard and Side-Wettable
- Industry’s Smallest Power over Coax (PoC)
RoR for Crystal-Free Operation on Serializers
ASIL-B Compliant in GMSL2 Mode (MAX96714/F)
Supports ASIL-B(D) Decomposition (MAX96714/F)
MAX96714: 6Gbps, GMSL2, ASIL-B
MAX96714F: 3Gbps, GMSL2, ASIL-B
MAX96714R: 3Gbps, GMSL2, QM, I²C Only

Part Models: 4
1ku List Price: Starting From $3.75
