ADUM4400

量产

5 kV RMS四通道数字隔离器

数据手册 (Rev. F)

产品模型: 16

Viewing:

产品详情

增强的系统级ESD保护性能，符合IEC 61000-4-x标准
安全和法规认证（RI-16封装）
- UL认证：1分钟5000 V rms，符合UL 1577标准
- CSA元件验收通知#5A
  - IEC 60601-1：250 V rms（加强）
  - IEC 60950-1：400 V rms（加强）
- VDE合规证书
- DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
  - V_IORM = 846 V峰值
低功耗工作
- 5 V电源：
  - 每个通道1.4 mA（最大值，0 Mbps至2 Mbps）
  - 每个通道4.3 mA（最大值，10 Mbps）
  - 每个通道34 mA（最大值，90 Mbps）
- 3.3 V电源
  - 每个通道0.9 mA（最大值，0 Mbps至2 Mbps）
  - 每个通道2.4 mA（最大值，10 Mbps）
  - 每个通道20 mA（最大值，90 Mbps）
双向通信
3.3 V/5 V电平转换
工作温度高达：105°C
高数据速率：DC至90 Mbps (NRZ)
精密时序特性
- 脉冲宽度失真：2 ns（最大值）
- 通道间匹配：2 ns（最大值）
高共模瞬变抗扰度：>25 kV/μs
输出使能功能
16引脚宽体SOIC封装版本(RW-16)
16引脚宽体SOIC封装版本，增强爬电距离(RI-16)

参考资料

欲了解ADI公司其它医疗产品及相关信息，请访问 www.analog.com/healthcare

技术文章：
采用iCoupler技术的IEC 60601-1兼容数字隔离器
高性能心电图(ECG)信号调理
可编程医用输液泵提供高可靠度和高性能

ADI 始终高度重视提供符合最高质量和可靠性水平的产品。我们通过将质量和可靠性检查纳入产品和工艺设计的各个范围以及制造过程来实现这一目标。出货产品的“零缺陷”始终是我们的目标。查看我们的质量和可靠性计划和认证以了解更多信息。

产品型号	引脚/封装图-中文版	文档	CAD 符号，脚注和 3D模型
ADUM4400ARIZ	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400ARIZ-RL	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400ARWZ	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400ARWZ-RL	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400BRIZ	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400BRIZ-RL	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400BRWZ	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400BRWZ-RL	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400CRIZ	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400CRIZ-RL	16-Lead SOIC (Increased Creepage)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400CRWZ	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400CRWZ-RL	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400WARWZ	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400WARWZ-RL	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400WBRWZ	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADUM4400WBRWZ-RL	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys
