MAX7300

PRODUCTION

2-Wire-Interfaced, 2.5V to 5.5V, 20-Port or 28-Port I/O Expander

Data Sheet (Rev. 8)

Part Models: 6
1ku List Price: Starting From $4.84

Viewing:

Part Details

400kbps I²C-Compatible Serial Interface
2.5V to 5.5V Operation
-40°C to +125°C Temperature Range
20 or 28 I/O Ports, Each Configurable as
- Push-Pull Logic Output
- Schmitt Logic Input
- Schmitt Logic Input with Internal Pullup
11µA (max) Shutdown Current
Logic Transition Detection for Seven I/O Ports

Part Models: 6
1ku List Price: Starting From $4.84

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX7300AAI+	28-SSOP-5.3_MM	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7300AAI+T	28-SSOP-5.3_MM	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7300AAX+	36-SSOP_W-7.62_MM	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7300AAX+T	36-SSOP_W-7.62_MM	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7300ATL+	40-LFCSP-6X6X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7300ATL+T	40-LFCSP-6X6X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
