MAX44246

PRODUCTION

36V, Low-Noise, Precision, Single/Quad/Dual Op Amps

Precision, Low-Noise Performance in High-Voltage Applications

Data Sheet (Rev. 7)

Part Models: 4
1ku List Price: Starting From $2.04

Viewing:

Part Details

Reduces Noise-Sensitive Precision Applications
- Low 9nV/√Hz Noise at 1kHz
- Integrated EMI Filter
Eliminates Cost of Calibration with Increased Accuracy and Patented Auto-Zero Circuitry
- Ultra-Low Input V_OS: 5µV (max)
- Low 20nV/°C (max) of Offset Drift
Suitable for High-Bandwidth Applications
- 1µs Fast Settling Time
- 5MHz Gain-Bandwidth Product
Low 0.55mA Per Channel (max) Quiescent Current
Wide Supply for High-Voltage Front-Ends
- 2.7V to 36V Supply Range
Rail-to-Rail Output

Part Models: 4
1ku List Price: Starting From $2.04

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX44246ASA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44246ASA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44246AUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44246AUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Mar 29, 2021 - 2140 WAFER FAB
		pcn_2140
MAX44246ASA+	PRODUCTION
MAX44246ASA+T	PRODUCTION
MAX44246AUA+	PRODUCTION
MAX44246AUA+T	PRODUCTION
Jan 14, 2019 - 1702D ASSEMBLY
		pcn_1702d
MAX44246ASA+	PRODUCTION
MAX44246ASA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

LTspice

Models for the following parts are available in LTspice:

MAX44246

SPICE Model 1

MAX44246 SPICE Macro Model

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
