MAX2620

PRODUCTION

10MHz to 1050MHz Integrated RF Oscillator with Buffered Outputs

Data Sheet (Rev. 2)

Part Models: 2
1ku List Price: Starting From $5.65

Viewing:

Part Details

Low-Phase-Noise Oscillator: -110dBc/Hz (25kHz offset from carrier) Attainable
Operates from Single +2.7V to +5.25V Supply
Low-Cost Silicon Bipolar Design
Two Output Buffers Provide Load Isolation
Insensitive to Supply Variations
Low, 27mW Power Consumption (V_CC = 3.0V)
Low-Current Shutdown Mode: 0.1µA (typ)

Part Models: 2
1ku List Price: Starting From $5.65

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX2620EUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX2620EUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX2620EUA+	PRODUCTION
MAX2620EUA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
