MAX2015

PRODUCTION

0.1GHz to 3GHz, 75dB Logarithmic Detector/Controller

0.1GHz to 3GHz, 75dB RF Log Detector/Controller Delivers Best Dynamic Range and Precision Over Temperature

Data Sheet (Rev. 2)

Part Models: 4
1ku List Price: Starting From $9.74

Viewing:

Part Details

Complete RF Detector/Controller
0.1GHz to 3GHz Frequency Range
Exceptional Accuracy Over Temperature
High Dynamic Range
2.7V to 5.25V Supply Voltage Range*
Scaling Stable Over Supply and Temperature Variations
Controller Mode with Error Output
Shutdown Mode with Typically 1µA of Supply Current
Available in 8-Pin µMAX® and TDFN Packages

*See Power-Supply Connections section located in the full datasheet.

Part Models: 4
1ku List Price: Starting From $9.74

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX2015ETA+	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX2015ETA+T	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX2015EUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX2015EUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
