MAX1925

PRODUCTION

Switch-Mode 1-Cell Li+ Chargers

Smallest, Simplest Switch-Mode Li+ Charger in 4mm x 4mm QFN Package

Data Sheet (Rev. 1)

Part Models: 2
1ku List Price: Starting From $2.24

Viewing:

Part Details

Small (4mm x 4mm) Package

4.25V to 12V Input Range (MAX1926)

Overvoltage Lockout at 6.1V (MAX1925)

±0.75% Battery Regulation Voltage

Set Charge Current with One Resistor

Automatic Input Power Sense

LED (or Logic-Out) Charge Status and Fault Indicator

Programmable Safety Timer

Autorestart at Cell = 4V

Thermistor Monitor Input

Part Models: 2
1ku List Price: Starting From $2.24

Documentation

Data Sheet 1

MAX1925-MAX1926: Switch-Mode 1-Cell Li+ Chargers Data Sheet (Rev.1) 11/15/2002

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX1925ETC+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1925ETC+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
