MAX44244

PRODUCTION

36V, Precision, Low-Power, 90µA, Single/Quad/Dual Op Amps

Precision, Low-Power Performance in High-Voltage Applications

Data Sheet (Rev. 6)

Part Models: 4
1ku List Price: Starting From $1.73

Viewing:

Part Details

Reduces Power for Sensitive Precision Applications
- Low 90µA Quiescent Current per Amplifier
Eliminates the Cost of Calibration with Increased Accuracy with Maxim’s Patented Autozero Circuitry
- Very Low Input Voltage Offset 7.5µV (max)
- Low 30nV/NC Offset Drift (max)
Low Noise Ideal for Sensor Interfaces and Transmitters
- 50nV/√Hz at 1kHz
- 0.5µV_P-P from 0.1Hz to 10Hz
1MHz Gain-Bandwidth Product
- EMI Suppression Circuitry
Rail-to-Rail Output
Wide Supply for High-Voltage Front Ends
- 2.7V to 36V Supply Range
µMAX, SO, SOT23, TSSOP Packages

Part Models: 4
1ku List Price: Starting From $1.73

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX44244AUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44244AUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44244AUK+	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44244AUK+T	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX44244AUA+	PRODUCTION
MAX44244AUA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
Operational Amplifiers 1
MAX9618	PRODUCTION	Single/Dual SC70, Zero-Drift, High-Efficiency, 1.5MHz Op Amps with RRIO

Tools & Simulations

LTspice

Models for the following parts are available in LTspice:

MAX44244

SPICE Model 1

MAX44244 SPICE Macro Model

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
