MAX1760

PRODUCTION

0.8A, Low-Noise, 1MHz, Step-Up DC-DC Converter

Data Sheet (Rev. 3)

Part Models: 8
1ku List Price: Starting From $3.04

Viewing:

Part Details

Up to 94% Efficiency
0.7V to 5.5V Input Range
Up to 800mA Output
Fixed 3.3V Output (or Adjustable from 2.5V to 5.5V)
PWM Synchronous-Rectified Topology
Low-Noise, Constant-Frequency Operation (1MHz)
0.1µA Logic-Controlled Shutdown
Synchronizable Switching Frequency
Adjustable Current Limit
Adjustable Soft-Start
10-Pin µMAX Package
10-Pin 3mm x 3mm TDFN Package

Part Models: 8
1ku List Price: Starting From $3.04

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX1760ETB+	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760ETB+T	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760EUB+	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760EUB+T	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760HETB+	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760HETB+T	Thin Dual Flatpack No Leads, Exposed Pad	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760HEUB+	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1760HEUB+T	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Switching Regulators & Controllers 2
MAX1763	PRODUCTION	1.5A, Low-Noise, 1MHz, Step-Up DC-DC Converter
MAX1765	PRODUCTION	800mA, Low-Noise, Step-Up DC-DC Converter with 500mA Linear Regulator
