MAX1726

PRODUCTION

12V, Ultra-Low-I_Q, Low-Dropout Linear Regulators

Data Sheet (Rev. 2)

Part Models: 8
1ku List Price: Starting From $0.97

Viewing:

Part Details

2µA Supply Current
Reverse-Battery Protection
+2.5V to +12V Input Voltage Range
Fixed 1.8V, 2.5V, 3.3V, and 5V Output Voltages (MAX1726)
Adjustable 1.5V to 5V Output Voltages (MAX1725)
20mA Guaranteed Output Current
1.5% Output Voltage Accuracy
Small 1µF Output Capacitor
Short-Circuit Protection
Thermal Protection
Tiny 5-Pin SOT23 Package

Part Models: 8
1ku List Price: Starting From $0.97

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX1726EUK18+	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK18+T	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK25+	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK25+T	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK33+	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK33+T	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK50+	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1726EUK50+T	5-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Apr 28, 2020 - 1703R ASSEMBLY
		pcn_1703r
MAX1726EUK33+	PRODUCTION	pcn_1703r
Jun 29, 2018 - 1703N ASSEMBLY
		pcn_1703n
MAX1726EUK33+T	PRODUCTION	pcn_1703n
Jan 11, 2021 - 1703RN ASSEMBLY
		pcn_1703rn
MAX1726EUK50+	PRODUCTION
MAX1726EUK50+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Linear Regulators 12
MAX1615	PRODUCTION	High-Voltage, Low-Power Linear Regulators for Notebook Computers
MAX1616	PRODUCTION	High-Voltage, Low-Power Linear Regulators for Notebook Computers
MAX8863	PRODUCTION	Low-Dropout, 120mA Linear Regulators
MAX8864	PRODUCTION	Low-Dropout, 120mA Linear Regulators

MAX8873	PRODUCTION	Low-Dropout 120mA Linear Regulators
MAX8874	PRODUCTION	Low-Dropout 120mA Linear Regulators
MAX8867	PRODUCTION	Low-Noise, Low-Dropout, 150mA Linear Regulators in SOT23
MAX8868	PRODUCTION	Low-Noise, Low-Dropout, 150mA Linear Regulators in SOT23
MAX8877	PRODUCTION	Low-Noise, Low-Dropout, 150mA Linear Regulators with '2982 Pinout
MAX8888	PRODUCTION	Low-Dropout, 300mA Linear Regulators in SOT23
MAX8880	PRODUCTION	12V, Ultra-Low-I_Q, Low-Dropout Linear Regulators with POK
MAX8881	PRODUCTION	12V, Ultra-Low-I_Q, Low-Dropout Linear Regulators with POK
