MAX8877

PRODUCTION

Low-Noise, Low-Dropout, 150mA Linear Regulators with '2982 Pinout

SOT23 Regulator Saves Space

Data Sheet (Rev. 2)

Part Models: 27
1ku List Price: Starting From $1.06

Viewing:

Part Details

Pin-Compatible with the Industry-Standard '2982
Low Output Noise: 30µV_RMS
Low 55mV Dropout at 50mA Output (165mV at 150mA output)
Low 85µA No-Load Supply Current
Low 100µA Operating Supply Current (even in dropout)
Thermal-Overload and Short-Circuit Protection
Reverse Battery Protection
Output Current Limit
Preset Output Voltages (±1.4% Accuracy)
10nA Logic-Controlled Shutdown

Part Models: 27
1ku List Price: Starting From $1.06

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX8877EUK18+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK18+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK25+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK25+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK28+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK28+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK29+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK29+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK30+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK30+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK32+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK32+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK33+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK33+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK36+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK36+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK50+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EUK50+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK18+	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK18+T	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK29+	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK29+T	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK30+	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK30+T	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK36+T	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK50+	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX8877EZK50+T	5-TSOT-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jan 11, 2021 - 1703RN ASSEMBLY
		pcn_1703rn
MAX8877EUK28+	PRODUCTION
MAX8877EUK28+T	PRODUCTION
MAX8877EUK32+	PRODUCTION
Jun 29, 2018 - 1703N ASSEMBLY
		pcn_1703n
MAX8877EUK32+T	PRODUCTION	pcn_1703n

This is the most up-to-date revision of the Data Sheet.
