MAX14714

PRODUCTION

Compact 6A Smart Power Path Selector

Provides the system power from two separate power sources with ultra-low supply current

Data Sheet (Rev. 0)

Part Models: 2
1ku List Price: Starting From $0.83

Viewing:

Part Details

Provides Robust Bidirectional Power Path
- Wide Operating Input Voltage: +1.6V to +5.5V
- 6A Continuous Current Capability
- Integrated Two 11mΩ (typ) MOSFET Switches
Enables Simple Power Switch Design
- Individual Path Control
- Automatic Power Path Control
- Automatic Soft-Start
- Powered by IN1, IN2, or OUT
Significantly Extends Battery Life
- Ultra-Low Quiescent Supply Current 2.5μA (typ)
- Fast Switchover
- Optimum Soft-Start Feature
Compact Package Saves Board Space
- 15-Bump 1.2mm x 2.0mm WLP

Part Models: 2
1ku List Price: Starting From $0.83

Documentation

Data Sheet 1

MAX14714: Compact 6A Smart Power Path Selector Data Sheet (Rev.0) 04/04/2018

Design Note 1

How to Choose a Power Path Selector 03/26/2019

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX14714EWL+	15-WLCSP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX14714EWL+T	15-WLCSP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jan 6, 2022 - 2196 WAFER FAB
		pcn_2196
MAX14714EWL+	PRODUCTION
MAX14714EWL+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
