HMC865

RECOMMENDED FOR NEW DESIGNS

32 Gbps Limiting Amplifier SMT

Data Sheet

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

Supports Data Rates up to 43 Gbps
Low Power Dissipation: 300 mW @ V_CC = +3.3V
Differential Small Signal Gain: 30 dB
High Input Sensitivity: 10 mV_P-P Differential

3-dB Bandwidth: 26.5 GHz
Adjustable Output Voltage Swing up to 800 mV_P-P Differential
16 Lead 3x3mm SMT package: 9mm²

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC865 Data Sheet 04/22/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC865LC3	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC865LC3TR	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC865LC3TR-R5	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
