HMC733

RECOMMENDED FOR NEW DESIGNS

Wideband VCO SMT w/Buffer Amplifier, 10 - 20 GHz

Data Sheet

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

Wide Tuning Bandwidth
Pout: +3 dBm
Low SSB Phase Noise: -90 dBc/Hz @100 kHz

No External Resonator Needed
Single Positive Supply: +5V @ 70 mA
24 Lead 4x4mm SMT Package: 16mm²

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC733 Data Sheet 04/22/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC733LC4B	24-Lead LCC (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC733LC4BTR	24-Lead LCC (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC733LC4BTR-R5	24-Lead LCC (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
ADF5709	RECOMMENDED FOR NEW DESIGNS	9.85 GHz to 20.5 GHz, Wideband, MMIC VCO

Tools & Simulations

ADIsimPLL™

ADIsimPLL enables the rapid and reliable evaluation of new high performance PLL products from ADI. It is the most comprehensive PLL Synthesizer design and simulation tool available today. Simulations performed include all key non-linear effects that are significant in affecting PLL performance. ADIsimPLL removes at least one iteration from the design process, thereby speeding the design- to-market.

Open Tool

Latest Discussions

No discussions on HMC733 yet. Have something to say?

Start a Discussion on EngineerZone®
