HMC1048A

RECOMMENDED FOR NEW DESIGNS

2.25 GHz to 18 GHz, MMIC, Double Balanced Downconverter

Data Sheet (Rev. B)
Part Models
3
1ku List Price
price unavailable
Viewing:

Part Details

  • Passive: no dc bias required
  • High input IP3: 20 dBm typical
  • LO to RF isolation: 25 dB typical
  • LO to IF isolation: 20 dB typical
  • RF to IF isolation: 15 dB typical
  • IF frequency range: dc to 4 GHz
  • Downconverter applications
  • 3 mm × 3 mm, 12-terminal ceramic leadless chip carrier package
HMC1048A
2.25 GHz to 18 GHz, MMIC, Double Balanced Downconverter
HMC1048A Functional Block Diagram HMC1048A Pin Configuration
