ADPL62933

RECOMMENDED FOR NEW DESIGNS

Nanopower μP Supervisor with Manual Reset and Watchdog Timer

Data Sheet (Rev. 1) Product Selection Table

Part Models: 2
1ku List Price: Starting From $0.82

Viewing:

Part Details

Ultra-Low 170nA (typ) Supply Current
Reset Thresholds from +1.575V to +4.625V in Approximately 100mV Increments
Six Minimum Reset Timeout Period Options from 10ms to 1200ms
Manual Reset Option
Watchdog Timer Option

Immune to Short V_CC Transients
Guaranteed Reset Valid to V_CC = +1.1V
Open-Drain RESET Output
No External Components
Small 5-Pin SOT23 Package

Part Models: 2
1ku List Price: Starting From $0.82

Documentation

Data Sheet 1

ADPL62933: Nanopower μP Supervisor with Manual Reset and Watchdog Timer Data Sheet (Rev.1) 02/19/2024

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
ADPL62933UK29D3S+	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADPL62933UK29D3S+T	Small-Outline Transistor Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Evaluation Kits

ADI Balanced Solutions Essentials Kit for the ADPL76030/ADPL26001 / ADPL13602 / ADPL54203 / ADPL20502 / ADPL62933 / ADPL62935 / ADPL63164

Buy Now View Details

Features and Benefits

Enables Immediate Testing of Eight Different Power Solutions and Supervisors
Includes Buck and Boost Converters, Buck/Boost Converter, No-Opto Isolated Flyback, and High-Performance Supervisors
Boards Designed with Through Holes for Prototyping on breadboards and existing circuits, as well as bench top testing

Product Details

The ADI Balanced Solutions Essentials Kit delivers products on ready-to-use boards for immediate testing and prototyping. The Balanced Solutions Essentials Kit features products from the Buck, Boost, Buck-Boost, Flyback, and High-Performance Supervisor product lines.
