EV高電圧ドライブトレイン試験ソリューション
電気自動車（EV）またはハイブリッド電気自動車（HEV）の高電圧（HV）ドライブトレインの試験には、インバータ、バッテリ・パック、トラクション・モータ、充電システムの大電力入力、大電力出力、および制御信号のエミュレートと測定などがあります。これらのテスト・システムは、ピーク電力レベルを供給し、最も厳しい条件をシミュレートできなければならず、最も堅牢なテストを行うためには、動的電源や電子負荷のような技術が必要となります。また、テスト・システムは、効率を向上させるために双方向または再生型である必要があります。数百から数千ボルトに及ぶ高電圧レベルでの安全性と堅牢な動作を確保するために、測定と制御は絶縁されていなければなりません。
Value and Benefits
Our high-power isolated signal chains enable the efficiency and robustness needed to test electric vehicle drivetrain components such as inverters, motors, chargers, and charger connections. Precision measurement and control are needed so that test systems will behave efficiently and reliably under all conditions, delivering power needed precisely when it is needed. Together, these solutions provide the mixed-signal circuitry necessary to accurately measure voltage and current in automotive testing scenarios.
Enables low-latency precision measurement and control
Provides robust isolation and protection
Accurately measures voltage and current
