MAX8527

PRODUCTION

1.425V to 3.6V Input, 2A, 0.2V Dropout LDO Regulators

Part Models
2
1ku List Price
Starting From $3.14

Part Details

  • 1.425V to 3.6V Input Voltage Range
  • Guaranteed 200mV Dropout at 2A Output Current
  • ±0.6% Initial Accuracy
  • ±1.4% Output Accuracy over Load/Line/Temperature (0°C to +85°C)
  • Compatible with Ceramic Capacitors
  • Fast Transient Response
  • 440µA Operating Supply Current
  • < 50µA Shutdown Supply Current
  • Short-Circuit Protection
  • Thermal-Overload Protection
  • Soft-Start Limits Inrush Current
  • 5mm x 6.4mm Footprint, 1.1mm Profile
MAX8527
1.425V to 3.6V Input, 2A, 0.2V Dropout LDO Regulators
Ask a Question

Documentation

Learn More

Hardware Ecosystem

Parts Product Life Cycle Description
Linear Regulators 2
MAX8516 PRODUCTION 1.425V to 3.6V Input, 1A, 0.2V Dropout LDO Regulators
MAX8556 PRODUCTION 4A Ultra-Low-Input-Voltage LDO Regulators
