MAX708

PRODUCTION

Low-Cost, µP Supervisory Circuits

Low-Cost Reset + Watchdog ICs

Data Sheet (Rev. 11) Product Selection Table

Part Models: 11
1ku List Price: Starting From $2.50

Viewing:

Part Details

Supervisory-Function Integration Significantly Improves System Reliability While Reducing Board Space
- µMAX Package
- Guaranteed Active Low RESET Valid at VCC = 1V
  - 200ms Reset Pulse Width
  - Debounced TTL/CMOS-Compatible Manual-Reset Input
  - Active-High Reset Output (MAX707/MAX708/MAX813L)
- Precision-Supply Voltage Monitor
  - 4.65V (MAX705/MAX707/MAX813L)
  - 4.40V (MAX706/MAX708)
- Voltage Monitor for Power-Fail or Low-Battery Warning

Part Models: 11
1ku List Price: Starting From $2.50

Documentation

Data Sheet 2

MAX705-MAX813L: Low-Cost, µP Supervisory Circuits Data Sheet (Rev.11) 08/29/2018

MAX705: Military Datasheet 09/15/2023

Reliability Data 1

MAX708 Reliability Data 01/12/2023

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX708C/D+	0-CHIP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708CPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708CSA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708CUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708CUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708EPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708ESA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708ESA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708ESA/GG8	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708MJA	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX708MJA/883B	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

May 1, 2020 - 1702R ASSEMBLY
		pcn_1702r
MAX708CSA+	PRODUCTION
MAX708ESA/GG8	PRODUCTION
Nov 9, 2018 - 1702C ASSEMBLY
		pcn_1702c
MAX708ESA+	PRODUCTION
MAX708ESA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
