MAX38902E

The MAX38902E is low-noise linear regulator that delivers up to 500mA of output current with only 14μV_RMS of output noise from 10Hz to 100kHz. This regulator maintains ±1% output accuracy over a wide input voltage range, requiring only 100mV of input-to-output headroom at full load. The 600µA no-load supply current is independent of dropout voltage. The MAX38902E has an 800Ω active discharge feature to quickly discharge output capacitors.

The MAX38902E has a resistor adjustable output voltage in the range of 0.8V to 5.0V and includes an active-low POK output. The device features a programmable output soft-start rate, output over-current and thermal overload protection.

The MAX38902E is offered in an 8-pin TDFN package.

Applications

• Audio Systems
• Communication Circuitry
• High-Resolution Data Acquisition Systems
