MAX38902B

PRODUCTION

10.5μVRMS Low Noise 500mA LDO Linear Regulator

10.5μVRMS Low-Noise, Low-Dropout, 500mA Linear Regulators in a 2mm x 2mm TDFN Package

Part Models
2
1ku List Price
Starting From $0.82

Part Details

  • 1.7V to 5.5V Input Voltage Range
  • 0.6V to 5.3V Output Voltage Range
  • 10.5μVRMS Output Noise, 10Hz to 100kHz
  • 365μA Operating Supply Current
  • 70dB PSRR at 10kHz
  • 500mA Maximum Output Current
  • ±1% DC Accuracy over Load, Line, and Temperature
  • 100mV (max) Dropout at 500mA Load (3.6VIN)
  • < 0.1μA Shutdown Supply Current
  • Stable with 2μF (min) Output Capacitance
  • Active Discharge of 800Ω at OUT
  • Programmable Soft-Start Rate
  • Overcurrent and Overtemperature Protection
  • Output-to-Input Reversed Current Protection
  • POK Output
  • Pin-to-Pin Compatible with MAX8902 (TDFN)
  • 1.22mm x 0.82mm, 2 x 3 Bump, 0.4mm Pitch WLP; or 2mm x 2mm, 8-Pin TDFN Package
MAX38902B
10.5μVRMS Low Noise 500mA LDO Linear Regulator
