MAX2661

PRODUCTION

400MHz to 2.5GHz Upconverters

Data Sheet (Rev. 1)

Part Models: 2
1ku List Price: Starting From $1.21

Viewing:

Part Details

RF Output Frequencies: 400MHz to 2.5GHz
Low Noise Figure: 9.3dB (900MHz, MAX2671)
+2.7V to +5.5V Single Supply
High Output Intercept Point (OIP3)
- 5.9dBm at 4.8mA (MAX2660)
- 7.1dBm at 8.3mA (MAX2661)
- 0.7dBm at 3.0mA (MAX2663)
- 9.6dBm at 11.8mA (MAX2671)
- 7.6dBm at 20.5mA (MAX2673)
1µA Shutdown Mode
Ultra-Small Surface-Mount Packaging

Part Models: 2
1ku List Price: Starting From $1.21

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX2661EUT+	6-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX2661EUT+T	6-SOT_23-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
