MAX25520

PRODUCTION

Automotive 2-Channel TFT-LCD Power Supply

Best in Class Solution Size and EMI

Data Sheet (Rev. 2)

Part Models: 6
1ku List Price: Starting From $1.25

Viewing:

Part Details

High Integration

Synchronous Boost Provides Positive Output at upto 10.5V/200mA (+12V for MAX25520ATEC)
Inverter Output Provides up to -10.5V/-200mA (-12V for MAX25520ATEC)

Low EMI

420kHz/2.1MHz Switching Frequency
Spread Spectrum

UV Diagnostics on All Outputs

Versatile

Complete Sequencing Flexibility
Compact TQFN Package
-40°C to +125°C Operating Temperature Range

AEC-Q100 Grade 1

Part Models: 6
1ku List Price: Starting From $1.25

Documentation

Data Sheet 1

MAX25520: Automotive 2-Channel TFT-LCD Power Supply Data Sheet (Rev.2) 10/12/2021

Technical Articles 2

TFT-Bias for Automotive Applications 08/20/2021

2-Channel TFT Bias Addresses Automotive LTPS Display Needs 08/24/2021

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX25520ATEB/V+	16-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX25520ATEB/V+T	16-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX25520ATEB/VY+	16-LFCSP_SS-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX25520ATEB/VY+T	16-LFCSP_SS-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX25520ATEC/V+	16-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX25520ATEC/V+T	16-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
