MAX214

PRODUCTION

Programmable DTE/DCE, +5V RS-232 Transceiver

Data Sheet (Rev. 1)

Part Models: 5
1ku List Price: Starting From $2.69

Viewing:

Part Details

Eliminates Null Modem Cables
Programmable DTE or DCE Serial Port
1µF Charge-Pump Capacitors
116kbps Data Rate-Guaranteed
20µA Shutdown Mode
Receivers Active in Shutdown

Part Models: 5
1ku List Price: Starting From $2.69

Documentation

Data Sheet 1

MAX214: Programmable DTE/DCE, +5V RS-232 Transceiver Data Sheet (Rev.1) 08/01/1995

Technical Articles 2

New RS-232 ICs Feature 1µA Supply Current, ±15kV ESD Protection, and 3V Operation 08/16/2002

Determining Clock Accuracy Requirements for UART Communications 08/07/2003

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX214CPI+	28-PDIP-600_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX214CWI+	28-SOIC_W-300_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX214CWI+T	28-SOIC_W-300_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX214EWI+	28-SOIC_W-300_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX214EWI+T	28-SOIC_W-300_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

May 21, 2018 - 1752 ASSEMBLY
		pcn_1752
MAX214CPI+	PRODUCTION	pcn_1752

This is the most up-to-date revision of the Data Sheet.

Latest Discussions

No discussions on MAX214 yet. Have something to say?
