MAX20320

PRODUCTION

Smart, Compact, 6A, Power-Path Selector with Reset Control

Provides the system power from two separate power sources with ultra-low supply current

Data Sheet (Rev. 4)
Part Models
2
1ku List Price
Starting From $1.05
Viewing:
  • Part Details
  • Documentation
  • Latest Discussions
    •

    Part Details

    • Provides Robust Bidirectional Power Path
      • Wide Operating Input Voltage: +1.6V to +5.5V
      • 6A Continuous-Current Capability
      • Two Integrated 11mΩ (typ) MOSFET Switches
    • Flexible System Design with Battery Connect, Reset, and Disconnect
      • I2C Control: MAX14740
      • Programmable Connect Time
      • Programmable Reset Setup Time
      • Programmable Reset Pulse Length
      • Programmable Disconnect Setup Time
      • Programmable Comparator Hysteresis
      • Programmable Input Autoselect
    • GPIO Control: MAX14741/MAX14742/MAX20320
      • Programmable Comparator Hysteresis
      • Programmable Input Autoselect
    • Long Battery Life
      • Ultra-Low Quiescent Supply Current 7.5µA (typ)
      • Fast Switchover
      • Optimum Soft-Start Feature
    MAX20320
    Smart, Compact, 6A, Power-Path Selector with Reset Control
    Ask a Question

    Documentation

    Data Sheet 1

    Design Note 1

    Request an NDA

    Complete documentation is available upon completion of a Non-Disclosure Agreement (NDA).

    Request an NDA
    Learn More

    Latest Discussions

    No discussions on MAX20320 yet. Have something to say?

    Start a Discussion on EngineerZone®
