MAX16923

PRODUCTION

Automotive 4-Output Display Power Solution with Watchdog

Industry's First Automotive PMIC for Automotive Display Applications

Data Sheet (Rev. 3)

Part Models: 4
1ku List Price: Starting From $3.75

Viewing:

Part Details

High Integration
- Complete Display Power Solution from Automotive Battery
- One High-Voltage 2.1A Buck Converter (5V or 3.3V)
- One High-Voltage 100mA Low-I_Q Linear Regulator (3.3V)
- One Low-Voltage 1.6A Buck Converter (3.3V, 1.8V, 1.2V, or 1.1V)
- One Low-Voltage Linear Regulator (3.3V, 1.8V, 1.5V, or 1.0V)
  - MAX16923GTPB: 75mA
  - MAX16923GTPC/MAX16923GTPE: 175mA
  - All other variants: 180mA
- Power-Good Outputs
Integrated Watchdog Timer
Robust and Low EMI
- Programmable Switching Frequency
- Internal Spread-Spectrum Oscillator
- Slew-Rate Controlled Switching
- Thermal Shutdown Protection
Compact TQFN20 4mm x 4mm Package

Part Models: 4
1ku List Price: Starting From $3.75

Documentation

Data Sheet 1

MAX16923: Automotive 4-Output Display Power Solution with Watchdog Data Sheet (Rev.3) 12/17/2019

Technical Articles 1

PMIC Streamlines Automotive TFT-LCD Display Design 12/03/2019

Request an NDA

Complete documentation is available upon completion of a Non-Disclosure Agreement (NDA).

Request an NDA

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX16923GTPA/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX16923GTPA/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX16923GTPC/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX16923GTPC/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
