MAX16138

RECOMMENDED FOR NEW DESIGNS

±0.7% Accuracy Single-Window Voltage Monitor with BIST

Provides More Diagnostics in Half the Size

Data Sheet (Rev. 0)

Part Models: 2
1ku List Price: Starting From $1.28

Viewing:

Part Details

±0.7% Allow Precision Supply Monitoring
BIST Enhances System Safety
Enables ASIL Compliance at System Level
Factory-Set Threshold 0.5V to 5V with 20mV Increment
Factory-Set Input Tolerance ±2% to ±9% UV/OV Threshold Window
Factory-Set Reset Timeout
Latched Overvoltage Fault Output
5μs Overvoltage Fault Response
Open-Drain/Push-Pull Reset Output
2mm x 2mm TDFN-8 Side-Wettable Package
-40°C to +125°C Temperature Range
AEC-Q100 Qualified

Part Models: 2
1ku List Price: Starting From $1.28

Documentation

Data Sheet 1

MAX16138: ±0.7% Accuracy Single-Window Voltage Monitor with BIST Data Sheet (Rev.0) 05/17/2022

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX16138ATA01/VY+	8-LFCSP_SS-2X2X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX16138ATA01/VY+T	8-LFCSP_SS-2X2X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Tools & Simulations

Design Tool 1

Window Voltage Monitor Calculator

IBIS Model 1

MAX16138 IBIS Model
