MAX1115

PRODUCTION

Single-Supply, Low-Power, Serial 8-Bit ADCs

Industry's Lowest-Power ADC Comes in SOT23

Part Models
2
1ku List Price
Starting From $1.20

Part Details

  • Single Supply
    • +2.7V to +3.6V (MAX1115)
    • +4.5V to +5.5V (MAX1116)
  • Input Voltage Range: 0 to VREF
  • Internal Track/Hold; 100kHz Sampling Rate
  • Internal Reference
    • +2.048V (MAX1115)
    • +4.096V (MAX1116)
  • SPI/QSPI/MICROWIRE-Compatible Serial Interface
  • Small 8-Pin SOT23 Package
  • Automatic Power-Down
  • Low Power
    • 175µA at 100ksps
    • 18µA at +3V and 10ksps
    • 1µA in Power-Down Mode
MAX1115
Single-Supply, Low-Power, Serial 8-Bit ADCs
Ask a Question

Documentation

Learn More

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts Product Life Cycle Description
Analog to Digital Converters 3
MAX1118 PRODUCTION Single-Supply, Low-Power, 2-Channel, Serial 8-Bit ADCs
MAX1119 PRODUCTION Single-Supply, Low-Power, 2-Channel, Serial 8-Bit ADCs
MAX1394 1.5V to 3.6V, 416ksps, 1-Channel True-Differential/2-Channel Single-Ended, 8-Bit, SAR ADCs
