LTC1174

PRODUCTION

High Efficiency Step-Down and Inverting DC/DC Converter

Data Sheet

Part Models: 23
1ku List Price: Starting From $5.17

Viewing:

Part Details

High Efficiency: Up to 94%
Peak Inductor Current Independent of Inductor Value
Short-Circuit Protection
Optimized for 5V to –5V Applications
Wide V_IN Range: 4V to 18.5V
Low Dropout Operation
Low-Battery Detector
Pin Selectable Current Limit
Internal 0.9Ω Power Switch: V_IN = 9V
Only Four External Components Required
130µA Standby Current
Active Low Micropower Shutdown

Part Models: 23
1ku List Price: Starting From $5.17
