LT1585

PRODUCTION

7A, 4.6A, 3A Low Dropout Fast Response Positive Regulators Adjustable and Fixed

Part Models: 13
1ku List Price: Starting From $5.45

Viewing:

Part Details

Fast Transient Response
Guaranteed Dropout Voltage at Multiple Currents
Load Regulation: 0.05% Typical
Trimmed Current Limit
On-Chip Thermal Limiting
Standard 3-Pin Power Package

Part Models: 13
1ku List Price: Starting From $5.45
