LT1039

PRODUCTION

RS232 Driver/Receiver with Shutdown

Data Sheet Product Selection Table

Part Models: 8
1ku List Price: Starting From $2.68

Viewing:

Part Details

Operates from ±5V to ±15V Supplies
Fully Protected Against Overload
Outputs can be Driven ±30V without Damage
Three-State Outputs; Outputs Open when Off
Bipolar Circuit—No Latch Up
±30V Input Range
Triple Driver/Receiver
No Supply Current in Shutdown
30kΩ Input Impedance
Meets All RS232 Specifications
16 Pin Version—Pin Compatible with MC145406
Available in SO Package
15kV ESD: LT1039A

Part Models: 8
1ku List Price: Starting From $2.68

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
LT1039CN#PBF	18-Lead PDIP (Narrow 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039CN16#PBF	16-Lead PDIP (Narrow 0.30 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039CSW#PBF	18-Lead SOIC (Wide 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039CSW#TRPBF	18-Lead SOIC (Wide 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039CSW16#PBF	16-Lead SOIC (Wide 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039IN#PBF	18-Lead PDIP (Narrow 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039ISW#PBF	18-Lead SOIC (Wide 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LT1039ISW#TRPBF	18-Lead SOIC (Wide 0.3 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Mar 7, 2019 - 19_0046 Assembly Transfer of 18,20,24,28 Lead PDIP to Cirtek
		PCN19_0046_Form Material_Report Detailed Change Description Qualification Results Summary
LT1039CN#PBF	PRODUCTION
LT1039IN#PBF	PRODUCTION
Oct 11, 2022 - 22_0241 Epoxy Change from Henkel 8290 to 8290A for PDIP Package
		PCN22_0241_Form Material_Report Qualification Results Summary
LT1039CN16#PBF	PRODUCTION
Aug 6, 2022 - 22_0172 Laser Top Mark Conversion for PDIP Packages Assembled in ADPG [PNG]
		PCN22_0172_Form Material_Report Delta Qualification Matrix
LT1039CN16#PBF	PRODUCTION
Aug 10, 2022 - 22_0176 Laser Top Mark Conversion for SOIC_W Packages Assembled in ADPG [PNG] and UTL
		PCN22_0176_Form Material_Report Delta Qualification Matrix
LT1039CSW#PBF	PRODUCTION
LT1039CSW#TRPBF	PRODUCTION
LT1039CSW16#PBF	PRODUCTION
LT1039ISW#PBF	PRODUCTION
LT1039ISW#TRPBF	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
