ICL7665

PRODUCTION

µP Voltage Monitor with Dual Over/Undervoltage Detection

Microprocessor Voltage Monitor with Dual Over/Undervoltage Detection

Data Sheet (Rev. 3) Product Selection Table

Part Models: 9
1ku List Price: Starting From $3.25

Viewing:

Part Details

µP Over/Undervoltage Warning
Improved Second Source
Dual Comparator with Precision Internal Reference
3µA Operating Current
2% Threshold Accuracy (ICL7665A)
1.6V to 16V Supply Voltage Range
On-Board Hysteresis Outputs
Externally Programmable Trip Points
Monolithic, Low-Power CMOS Design

Part Models: 9
1ku List Price: Starting From $3.25

Documentation

Data Sheet 1

ICL7665: µP Voltage Monitor with Dual Over/Undervoltage Detection Data Sheet (Rev.3) 11/13/2015

Reliability Data 1

ICL7665 Reliability Data 01/12/2023

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
ICL7665ACPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665ACSA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665ACSA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665AEPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665AESA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665AESA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665BCPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665CSA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ICL7665CSA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

May 22, 2018 - 1702N ASSEMBLY
		pcn_1702n
ICL7665CSA+	PRODUCTION
ICL7665CSA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
