HMC745

RECOMMENDED FOR NEW DESIGNS

13 Gbps, Fast Rise Time XOR/XNOR Gate with Programmable Output Voltage and Positive Supply

Data Sheet (Rev. D)

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

Inputs terminated internally at 50 Ω
Differential and single-ended operation
Fast rise and fall times: 21/19 ps
Low power consumption: 240 mW (typical)
Programmable Differential
Output voltage swing: 600 mV to 1200 mV
Propagation delay: 95 ps
Single supply: 3.3 V
16-terminal, ceramic 3 mm × 3 mm LCC package

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC745: 13 Gbps, Fast Rise Time XOR/XNOR Gate with Programmable Output Voltage and Positive Supply Data Sheet (Rev.D) 04/22/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC745LC3	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC745LC3TR	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC745LC3TR-R5	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
