HMC729

RECOMMENDED FOR NEW DESIGNS

26 GHz, T Flip-Flop w/Reset

Data Sheet

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

Supports Clock Frequencies up to 26 GHz
Differential & Singe-Ended Operation
Fast Rise and Fall Times: 18/17 ps
Low Power Consumption: 270 mW typ.

Propagation Delay: 95 ps
Single Supply: -3.3V
16 Lead Ceramic 3×3mm SMT Package: 9mm²

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC729 Data Sheet 06/03/2020

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC729LC3C	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC729LC3CTR	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC729LC3CTR-R5	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
