HMC723LP3E

PRODUCTION

13 Gbps Fast Rise Time D-Type Flip-Flop with Programmable Output Voltage

Data Sheet

Part Models: 2
1ku List Price: price unavailable

Viewing:

Part Details

Supports High Data Rates: up to 13 Gbps
Differential & Singe-Ended Operation
Fast Rise & Fall Times: 19/17 ps
Low Power Consumption: 260 mW typ.
Programmable Differential Output Voltage Swing: 700 - 1300 mV

Propagation Delay: 105 ps
Single Supply: -3.3V
16 Lead 3×3mm
SMT Package: 9mm²

Part Models: 2
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC723LP3E Data Sheet 10/20/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC723LP3E	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC723LP3ETR	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Apr 19, 2022 - 22_0048 Addition of ASE Korea as an Alternate Assembly Site for Select LFCSP Products
		PCN22_0048_Form Material_Report Qualification Results Summary Detailed Change Description
HMC723LP3E	PRODUCTION
HMC723LP3ETR	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
