HMC602

LAST TIME BUY

70 dB, Logarithmic Detector/Controller SMT, 1 - 8000 MHz

Data Sheet Product Selection Table

Part Models: 4
1ku List Price: price unavailable

Viewing:

Part Details

Wide Dynamic Range: up to 70 dB
High Accuracy: ±1 dB with 60 dB Range Up To 6 GHz
Fast: 10ns Output Response Time
Supply Voltage: +5V
Power-Down Mode
Excellent Stability over Temperature
Buffered Temperature Sensor Output
4x4mm Leadless SMT Package

Part Models: 4
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC602 Data Sheet 04/22/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC602LP4	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC602LP4E	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC602LP4ETR	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC602LP4TR	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jun 6, 2022 - 22_0048 Addition of ASE Korea as an Alternate Assembly Site for Select LFCSP Products
		PCN22_0048_Form Material_Report Qualification Results Summary Detailed Change Description
HMC602LP4E	LAST TIME BUY
HMC602LP4ETR	LAST TIME BUY
Jul 28, 2022 - 22_0023 Product Discontinuance for Select Analog Devices Parts (ADFXXXX, HMCXXX)
		PDN22_0023_Form Material_Report
HMC602LP4	LAST TIME BUY
HMC602LP4E	LAST TIME BUY
HMC602LP4ETR	LAST TIME BUY
HMC602LP4TR	LAST TIME BUY
