DS1087L

PRODUCTION

3.3V Spread-Spectrum EconOscillator

Industry's Only 3V Single-Chip Oscillator Reduces EMI Up to 20dB

Data Sheet (Rev. 1)

Part Models: 12
1ku List Price: Starting From $1.38

Viewing:

Part Details

Factory Programmed Square-Wave Generator from 130kHz to 66.6MHz
No External Timing Components Required
EMI Reduction
2.7V to 3.6V Supply
User Programmable Down to 130kHz with Divider (Dependent on Master Oscillator Frequency)
2% or 4% Selectable Dithered Output
Glitchless Output-Enable Control
2-Wire Serial Interface
Nonvolatile Settings
Power-Down Mode
Programmable Output Power-Down/Disable Mode

Part Models: 12
1ku List Price: Starting From $1.38

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
DS1087LU-21H+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-21H+T&R	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-23C+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-23C+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-266+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-266+T&R	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-26A+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-26A+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-40K+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-447+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-447+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
DS1087LU-4CL+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
DS1087LU-21H+	PRODUCTION
DS1087LU-266+	PRODUCTION
DS1087LU-266+T&R	PRODUCTION
DS1087LU-26A+	PRODUCTION
DS1087LU-26A+T	PRODUCTION
DS1087LU-40K+	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
Oscillators 7
DS1086	PRODUCTION	Spread-Spectrum EconOscillator
DS1085	PRODUCTION	EconOscillator Frequency Synthesizer
DS1085L		3.3V EconOscillator Frequency Synthesizer
DS1077	PRODUCTION	EconOscillator™/Divider

DS1077L	PRODUCTION	3V EconOscillator/Divider
DS1075		EconOscillator/Divider
DS1073		3-Volt EconOscillator/Divider
