ADP3605

PRODUCTION

120 mA Switched Capacitor Voltage Inverter with Regulated Output

Data Sheet (Rev. B) Product Selection Table

Part Models: 2
1ku List Price: Starting From $2.13

Viewing:

Part Details

Fully Regulated Adjustable Output Voltage
High Output Current: 120 mA
Output Accuracy: ±3%
250 kHz Switching Frequency

Low Shutdown Current: 2 µA Typical
Input Voltage Range from 3 V to 6 V
SO-8 Package
–40°C to +85°C Ambient Temperature Range

Part Models: 2
1ku List Price: Starting From $2.13

Documentation

Data Sheet 1

ADP3605: 120 mA Switched Capacitor Voltage Inverter with Regulated Output Data Sheet (Rev.B) 10/03/2002

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
ADP3605ARZ	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADP3605ARZ-R7	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Dec 8, 2014 - 14_0240 ADP3605 Die Revision
		PCN14_0240_Form Material_Report
ADP3605ARZ
ADP3605ARZ-R7

This is the most up-to-date revision of the Data Sheet.
