ADM811

PRODUCTION

Microprocessors Supervisory Circuit in 4-Lead SOT-143, Logic Low RESET Bar Output

Data Sheet (Rev. H)

Part Models: 10
1ku List Price: Starting From $0.56

Viewing:

Part Details

Superior upgrade for MAX811/MAX812
Specified over temperature
Low power consumption: 5 μA typical
Precision voltage monitor: 2.5 V, 3 V, 3.3 V, 5 V options
Reset assertion down to 1 VCC
Power-on reset: 140 ms minimum
Logic low RESET output
Built-in manual reset

Part Models: 10
1ku List Price: Starting From $0.56

Documentation

Data Sheet 1

ADM811/ADM812: Microprocessor Supervisory Circuit in 4-Lead SOT-143 with DSP Data Sheet (Rev.H) 11/14/2006

Application Note 1

AN-349: Keys to Longer Life for CMOS 10/15/2002
