ADF4206

Obsolete

Dual, Integer-N 0.5 GHz / 0.5 GHz PLL

Data Sheet (Rev. A)

Viewing:

Part Details

ADF4206: 550 MHz/550 MHz
ADF4208: 2.0 GHz/1.1 GHz
2.7 V to 5.5 V Power Supply
Selectable Charge Pump Supply (V_P) Allows Extended Tuning Voltage in 3 V Systems
Selectable Charge Pump Currents
On-Chip Oscillator Circuit
Selectable Dual Modulus Prescaler
- RF2: 32/33 or 64/65
- RF1: 32/33 or 64/65
3-Wire Serial Interface
Power-Down Mode

Documentation

Data Sheet 1

ADF4206/ADF4208: Dual RF PLL Frequency Synthesizers Data Sheet (Rev.A) 03/01/2001

Application Note 2

AN-30: Ask the Applications Engineer - PLL Synthesizers 12/06/2004

AN-873: Lock Detect on the ADF4xxx Family of PLL Synthesizers 03/13/2025

Frequently Asked Question 1

FAQ 05/19/2025

This is the most up-to-date revision of the Data Sheet.
