ADCLK944

RECOMMENDED FOR NEW DESIGNS

2.5 V/3.3 V, Four LVPECL Outputs, SiGe Clock Fanout Buffer

Part Details

  • Operating frequency: 7.0 GHz
  • Broadband random jitter: 50 fs rms
  • On-chip input terminations
  • Power supply (VCC − VEE): 2.5 V to 3.3 V
ADCLK944
2.5 V/3.3 V, Four LVPECL Outputs, SiGe Clock Fanout Buffer
