AD8240

LAST TIME BUY

LED Driver/Monitor

Data Sheet (Rev. 0)

Viewing:

Part Details

PWM input for LED Brightness Control
Open LED Detection
Latch-off Overcurrent Protection
Constant Voltage Regulated Output
Regulated Voltage Range: 12.5V to 27V

Supply range: 9V to 27 V
Operating current: 300 µA
Shutdown current: 10 µA
Temperature range -40°C to +125°C
8-lead MSOP package

Documentation

Data Sheet 1

AD8240: LED Driver/Monitor Data Sheet (Rev.0) 04/01/2004

Application Note 1

AN-669: Effectively Applying the AD628 Precision Gain Block (Rev.0) 02/14/2015

Technical Articles 2

Auto-Zero Amplifiers 03/01/2010

High-performance Adder Uses Instrumentation Amplifiers 09/03/2009

This is the most up-to-date revision of the Data Sheet.
