AD74115H
RECOMMENDED FOR NEW DESIGNSSingle-Channel, Software Configurable Input and Output with HART Modem
- Part Models
- 2
- 1ku List Price
- Starting From $9.62
Part Details
- Single-channel software configurable input and output
- Multiple configurable modes to a single pin
- Voltage input
- Current input
- Voltage output
- Current output
- Digital input
- Digital output
- 2-wire, 3-wire, or 4-wire RTD measurements
- Thermocouple measurement
- Overvoltage tolerant on screw terminal facing pins, powered or unpowered
- Auxiliary high voltage sense pins
- 10 ppm/°C reference temperature coefficient
- 16-bit, Σ-Δ ADC with optional 50 Hz and 60 Hz rejection
- 14-bit monotonic DAC
- Unipolar and bipolar capability
- Integrated HART modem
- On-chip diagnostics including open-circuit and short-circuit detection
- Internal temperature sensor, ±5°C accuracy
- SPI-compatible
- Wide power supply range
- Programmable power control
- Temperature range: −40°C to +105°C
- 48-lead LFCSP
The AD74115H is a single-channel, software-configurable, input and output device for industrial control applications. The AD74115H provides a wide range of use cases, integrated on a single chip. These use cases include analog output, analog input, digital output, digital input, resistance temperature detector (RTD), and thermocouple measurement capability. The AD74115H also has an integrated HART modem. A serial peripheral interface (SPI) is used to handle all communications to the device, including communications with the HART modem. The digital input and digital outputs can be accessed via the SPI or the general-purpose input and output (GPIO) pins to support higher speed data rates.
The device features a 16-bit, Σ-Δ analog-to-digital converter (ADC) and a 14-bit digital-to-analog converter (DAC). The AD74115H contains a high accuracy 2.5 V on-chip reference that can be used as the DAC and ADC reference.
Power and isolation can be provided using the ADP1034 companion product. When using the ADP1034 and AD74115H together, programmable power control (PPC) is available on the positive analog supply, AVDD, which allows for an optimized power solution in the end application. An on-chip charge pump can be enabled if unipolar capability is required.
APPLICATIONS
- Isolated industrial control systems
- Process control
- Factory automation
- Building control systems
Documentation
Data Sheet 1
User Guide 1
Application Note 1
Video 4
Device Drivers 2
3rd Party Solutions 1
Analog Dialogue 1
