ADH518S
Aerospace, GaAs, PHEMT, MMIC, Low Noise Amplifier, 20 GHz to 32 GHz
Viewing:
产品详情
- Noise Figure: 3 dB
- Gain: 15 dB
- OIP3: 23 dBm
- Single Positive Supply: +3V @ 65 mA
- 50 Ohm Matched Input/Output
- Screened in accordance with MIL-38534, Class K
- Die Size: 2.27 mm x 1.32 mm x 0.1 mm
The ADH518S chip is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) which covers the 20 GHz to 32 GHz frequency range. The ADH518S provides 15 dB of small signal gain, 3 dB of noise figure and has an output IP3 greater than 23 dBm. The chip can easily be integrated into hybrid or MCM assemblies due to its small size.
Applications
- Point-to-Point Radios
- Point-to-Multi-Point Radios
- VSAT
- Test Equipment
- Sensors
- Military and Space
