ADH465S
Aerospace, GaAs, pHEMT, MMIC, Distributed Driver Amplifier, DC to 20 GHz.
产品详情
- Gain: 17 dB
- Output Voltage to 10 Vp-p
- Saturated Output Power: +24 dBm
- Supply Voltage: +8V @ 160 mA
- 50 Ohm Matched Input/Output
- Die Size: 3.044 mm x 1.559 mm x 0.1 mm
- Screened in accordance with MIL-PRF-38534, Class K
The ADH465S is a GaAs MMIC PHEMT Distributed Driver Amplifier die which operates between DC and 20 GHz. The amplifier provides 17 dB of gain, 2.5 dB noise figure and +24 dBm of saturated output power while requiring only 160 mA from a +8V supply. Gain flatness is excellent at ±0.25 dB as well as ±1 deg deviation from linear phase from DC to 10 GHz making the ADH465S ideal for optical networking, driver amplifier as well as test equipment applications. The ADH465S amplifier I/Os are internally matched to 50 Ohms facilitating easy integration into Multi-Chip-Modules (MCMs).
Applications
- Modulator Driver
- Test Instrumentation
- Military & Space
