ADH462S
2 GHz to 20 GHz, Low Noise Amplifier
产品详情
- Noise figure: 2 dB @ 10 GHz
- Gain: 15 dB
- P1dB Output Power: +15 dBm @ 10 GHz
- Self-Biased: +5V @ 63 mA
- 50 Ohm Matched Input/Output
- Die size: 3.02 mm x 1.3 mm x 0.1 mm
- Screened in accordance with MIL-PRF-38534, Class K
The ADH462S is a GaAs MMIC pHEMT Low Noise distributed amplifier which operates between 2 GHz and 20GHz. The amplifier provides 15 dB of small signal gain, 2 dB noise figure, and up to +15 dBm of output power at 1dB compression. Gain flatness is excellent at ± 0.5 dB from 6 GHz to 14 GHz making the ADH462S ideal for numerous applications. The ADH462S requires a single supply of +5V @ 63 mA and is the self-biased version of the ADH463S. The wideband amplifier I/Os are internally matched to 50 ohms facilitating integration into multi-Chip modules (MCMs).
Applications
- Test Instrumentation
- Microwave Radio
- VSAT
- Military & Space
