MAXQ1050
NOT RECOMMENDED FOR NEW DESIGNSDeepCover Secure Microcontroller with USB and Hardware Cryptography
Small Footprint Cryptographic Microcontroller with Advanced Physical Security
- Part Models
- 1
- 1ku List Price
- price unavailable
Part Details
- High-Performance, Low-Power, 32-Bit MAXQ30 RISC Core
- Operates from USB Power or Single 3.3V Supply
- Runs from 20MHz (typ) Internal Oscillator
- Supports External 12/24MHz Crystal Oscillator for Microcontroller and USB Operation
- On-Chip 2x/4x Clock Multiplier
- 16-Bit Instruction Word, 32-Bit Internal Data Bus
- 16 x 32-Bit Accumulators
- 16 x 32-Bit General-Purpose Working Registers
- Up to 20 General-Purpose I/O Pins
- 5V Tolerant I/O
- Virtually Unlimited Software Stack
- Optimized for C-Compiler (High-Speed/Density Code)
- Memory
- 128KB Flash Memory, 512 x 32 Page Size
- Flash Memory Supports 20k Erase/Write Cycles per Sector
- 256B of Secure NV SRAM
- 4KB Battery-Backed NV SRAM
- 12KB SRAM
- Secure JTAG/TAP for In-System Programming and On-Chip Debugger Access
- Security
- Unique 64-Bit Serial Number
- Tamper Detection with Rapid Key/Data Destruction
- Secret Key Destruction on Tamper Events
- Permanent Loader Lockout Option
- Proprietary Code Scrambling Technique Using Random Keys
- Hardware Accelerators for AES, RSA, DSA, ECDSA, DES, 3DES, SHA-1, SHA-224, SHA-256
- True Hardware Random-Number Generator
- Temperature and Voltage Sensors to Detect Attacks
- Two Self-Destruct Input Pins
- Additional Peripherals
- Power-Fail Warning
- Power-On-Reset/Brownout Reset
- Full-Speed USB Device with Six Endpoint Buffers and Integrated Transceiver
- ISO 7816 Smart Card UART with FIFO
- 16-Bit Programmable Timers/Counters with Prescaler, Capture/Compare, and PWM
- SPI Master/Slave Hardware
- Programmable Watchdog Timer
- Up to 20 General-Purpose I/O Pins with Eight External Interrupts
The device uses the 32-bit, pipelined, highly efficient MAXQ30 microcontroller core. It integrates 128KB flash memory, 12KB of volatile SRAM, 4KB of battery-backed erasable NV SRAM, and 256B of battery-backed, secure zeroization NV SRAM. An additional 1.5KB of volatile cryptographic memory can also be used as general-purpose data memory. The 256B of battery-backed NV SRAM can be used for key storage and other critical data. The 256B memory can be erased in less than 1µs using a single pulse ("rapid zeroization"), even in battery-backed mode.
The device is powered either from the USB bus or by a separate 3.3V voltage supply. A battery connection is provided for applications that want to maintain secret key data for years without draining the battery from application use. In battery-backed mode, the NV SRAM and security sensors consume less than 240nA (typ). Battery backup is optional; applications can choose to store critical data in the flash memory when the cost of the battery outweighs the benefits of constant monitoring for tamper conditions.
Applications
- Certificate Management
- e-Commerce
- Electronic Signature Generation
- Pay-per-Play
- Prepaid Utility
- Secure Access Control
- Security and Banking Tokens
- Smart Grid Security
