MAX9920

PRODUCTION

-20V to +75V Input Range, Precision Uni-/Bidirectional, Current-Sense Amplifiers

Current-Sense Amplifiers with Input Common Range that Extends Well Below Ground (-20V)

Data Sheet (Rev. 10)

Part Models: 4
1ku List Price: Starting From $1.35

Viewing:

Part Details

Reduce Protective Clamping for High Inductive Kickback Voltage
- -20V to +75V Input Common-Mode Voltage Range
Supports Wide Range of Precision AC and DC Current Sensing Applications
- Uni- or Bidirectional Current Sensing
- 0.6% (max) Gain Accuracy Error
- 400µV (max) Input Offset Voltage
- 120kHz, -3dB Bandwidth (MAX9919N)
- Reference Input for Bidirectional OUT
- Rail-to-Rail Output
Saves Board Space
- 8-Pin SOIC Package
- Single-Supply Operation (4.5V to 5.5V)
AEC-Q100 Qualified (MAX9918ASA/V+, MAX9919FASA/V+, MAX9919NASA/V+, MAX9920ASA/V+ Only)

Part Models: 4
1ku List Price: Starting From $1.35

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX9920ASA+	8-SOIC_N-150_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX9920ASA+T	8-SOIC_N-150_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX9920ASA/V+	8-SOIC_N-150_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX9920ASA/V+T	8-SOIC_N-150_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
