MAX913

PRODUCTION

Single/Dual, Ultra-Fast, Low-Power, Precision TTL Comparators

Data Sheet (Rev. 2)

Part Models: 12
1ku List Price: Starting From $4.26

Viewing:

Part Details

Ultra Fast (10ns)
Single +5V or Dual ±5V Supply Operation
Input Range Extends Below Negative Supply
Low Power: 6mA (+5V) Per Comparator
No Minimum Input Signal Slew-Rate Requirement
No Power-Supply Current Spiking
Stable in the Linear Region
Inputs Can Exceed Either Supply
Low Offset Voltage: 0.8mV
Now Available in a Small µMAX® Package

Part Models: 12
1ku List Price: Starting From $4.26

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX913C/D	0-CHIP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913C/W+	N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913CPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913CSA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913CSA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913EPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913EPA/GG8	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913ESA+	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913ESA+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913EUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913EUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX913MSA/PR+T	Small-Outline IC, Narrow (0.15in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Oct 30, 2020 - 1702R2 ASSEMBLY
		pcn_1702r2
MAX913CSA+	PRODUCTION
MAX913CSA+T	PRODUCTION
MAX913ESA+	PRODUCTION
MAX913ESA+T	PRODUCTION
Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX913EUA+	PRODUCTION
MAX913EUA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
